pptx/multiple-slides

Metadata

XPath assertions

Render assertions

Generator source

scripts/gen_multiple_slides.py

#!/usr/bin/env python3
"""Generate ``fixtures/pptx/multiple-slides.pptx``.

A three-slide presentation — each slide carries its own title —
exercising the presentation-level <p:sldIdLst> and the slideN.xml
part-name convention. Designed to satisfy the assertions in
``features/pptx/multiple-slides.json``.
"""

from __future__ import annotations

from pathlib import Path

from pptx import Presentation

import datetime as _dt
_REPRODUCIBLE_DT = _dt.datetime(2000, 1, 1, 0, 0, 0)

_REPO_ROOT = Path(__file__).resolve().parent.parent
_OUT = _REPO_ROOT / "fixtures" / "pptx" / "multiple-slides.pptx"


def main() -> int:
    prs = Presentation()
    # slide_layouts[5] is the "title only" layout — a title placeholder and
    # nothing else. Each slide here uses it so the asserted title text is
    # the only non-boilerplate content we add.
    for text in ("Slide one title", "Slide two title", "Slide three title"):
        slide = prs.slides.add_slide(prs.slide_layouts[5])
        slide.shapes.title.text = text

    _OUT.parent.mkdir(parents=True, exist_ok=True)
    prs.save(_OUT, zip_date_time=_REPRODUCIBLE_DT)
    print(_OUT)
    return 0


if __name__ == "__main__":
    raise SystemExit(main())

Manifest (expanded)

{
  "$schema": "../manifest.schema.json",
  "id": "pptx/multiple-slides",
  "title": "Presentation with multiple slides",
  "format": "pptx",
  "category": "slide-content",
  "summary": "A presentation with three slides — each carries its own title — registered under p:sldIdLst in ppt/presentation.xml and emitted as slide1.xml, slide2.xml, slide3.xml.",
  "spec": {
    "source": "ecma-376-5-part-1",
    "clause": "19.3.1",
    "element": "p:sldIdLst",
    "rnc_reference": "spec/ecma-376-5/part-1/rnc/PresentationML.rnc",
    "xsd_reference": "spec/ecma-376-5/part-1/xsd/pml.xsd",
    "notes": "python-pptx registers each slide added via slides.add_slide() as a <p:sldId> under <p:sldIdLst> in ppt/presentation.xml, and writes each slide's body as ppt/slides/slideN.xml. The manifest asserts one title per slide-part rather than a count on sldIdLst, since the XPath assertion vocabulary doesn't include equal-count."
  },
  "fixtures": {
    "machine": "pptx/multiple-slides",
    "office": "pptx/multiple-slides"
  },
  "generator": {
    "python": "scripts/gen_multiple_slides.py"
  },
  "assertions": [
    {
      "id": "slide1-title-present",
      "part": "ppt/slides/slide1.xml",
      "namespaces": {
        "p": "http://schemas.openxmlformats.org/presentationml/2006/main",
        "a": "http://schemas.openxmlformats.org/drawingml/2006/main"
      },
      "xpath": "//a:t[normalize-space()='Slide one title']",
      "must": "exist",
      "description": "Slide 1 must carry the text 'Slide one title'."
    },
    {
      "id": "slide2-title-present",
      "part": "ppt/slides/slide2.xml",
      "namespaces": {
        "p": "http://schemas.openxmlformats.org/presentationml/2006/main",
        "a": "http://schemas.openxmlformats.org/drawingml/2006/main"
      },
      "xpath": "//a:t[normalize-space()='Slide two title']",
      "must": "exist",
      "description": "Slide 2 must carry the text 'Slide two title'."
    },
    {
      "id": "slide3-title-present",
      "part": "ppt/slides/slide3.xml",
      "namespaces": {
        "p": "http://schemas.openxmlformats.org/presentationml/2006/main",
        "a": "http://schemas.openxmlformats.org/drawingml/2006/main"
      },
      "xpath": "//a:t[normalize-space()='Slide three title']",
      "must": "exist",
      "description": "Slide 3 must carry the text 'Slide three title'."
    }
  ],
  "render_assertions": [
    {
      "id": "multiple-slides-three-slide-nodes",
      "kind": "css_selector",
      "selector": ".slide, [data-slide], section[data-slide], section.slide, .pptx-slide",
      "must": "equal-count",
      "count": 3,
      "description": "The renderer must emit exactly three slide container nodes."
    },
    {
      "id": "multiple-slides-title-one-visible",
      "kind": "css_selector",
      "selector": ".slide, [data-slide], section[data-slide], section.slide, .pptx-slide",
      "must": "match-text",
      "value": "Slide one title",
      "description": "The first rendered slide must carry the text 'Slide one title'. Fallback text-match in case the count assertion passes but slide ordering is unclear."
    }
  ]
}
